MODEL 2-C15 and 2-C12
Performance
(3.82 cubic inch per revolution gear motor for Model
2-C15 and 3.19 For Model 2-C12)
| Maximum Operating Pressure |
3000 PSIG |
| Input Flow Required For 2400 RPM |
Model 2-C15 - 44 GPM
Model 2-C12 - 37 GPM |
| Recommended Cranking Speed *** |
2400 RPM |
| Maximum Cranking Speed |
3000 RPM |
| Torque at Maximum Operating
Pressure |
Model 2-C15 - 133 FT LB
Model 2-C12 - 109 FT LB |
| Maximum Speed at 1/8 Revolution * |
720 RPM |
| Minimum Speed at 1/8 Revolution * |
** |
*The inertia drive requires controlled
increase of flow from zero for the first revolution of the motor (engine
not rotating). First 1/8 revolution is critical for starter pinion
reliability and life.
** Reliable engagement, or
240 RPM
*** Most applications
Recommended Engine Sizes
| |
Model 2-C15 |
Model 2-C12 |
| Diesel
Engines |
1000-2500 cu.in.
16-40 liters |
700-1500 cu. in.
11-25 liters |
Natural gas engines with high driven
loads such as compressors - use diesel recommendation
otherwise, consult factory.
Drive Specifications
| Drive Housing
Mounting To Engine |
SAE #3 |
| Drive Housing Part
Number |
301-5B |
| Drive Part Number |
301-9-RH3A |
| Number Teeth |
12 |
| Pitch |
6/8 |
